    8" 203mm Down Hole Motor For Oil And Gas Well Directional Drilling

    Ask Lasest Price
    Supply Ability : 30000PCs per Year
    Delivery Time : 5-15work days
    Certification : ISO9001
    Price : Negotiable
    Payment Terms : T/T
    • Product Details
    • Company Profile

    8" 203mm Down Hole Motor For Oil And Gas Well Directional Drilling

    Local aging of elastomer occurs frequently in conventional downhole motors because the elastomer thickness of conventional downhole motor is different. The elastomer are worn not evenly. That leads to a power section failure soon. This problem is solved greatly in Even Wall Thickness downhole motors. The elastomer of even wall thickness downhole motor is the same. It is worn evenly in drilling operation so it extends the working life greatly. Even wall thickness downhole motors also provide 50% more toque than conventional downhole motors and longer working life in directional well drilling.

    Our even wall thickness downhole motor are able to be custom made as per the customers detailed requirements if the required size is not available in below tables.

    Availability of our small size downhole motor:


    Downhole Motor SpecificationODBit SizeConnectionLobeStageFlow RateRPMWorking Pressure DropOutput ToqueMax Pressure DropMax ToqueOperating WOBMax WOBOutput Power
    mmInmmInTopBottomLpmGpmMPaPsiN.mlb-ftMPaPsiN.mlb-ftkNlbkNlbKWHP
    4LZ-203-6.1-9502038251-3119-7/8~12-1/46-5/8REG6-5/8REG4:56.11510-3410399-90197-21814.182056181901341721.27308527285201251503300022048400415557
    7LZ-203-3.8-12102038251-3119-7/8~12-1/46-5/8REG6-5/8REG7:83.81510-3410399-90162-1408.831281176861304513.25192126529195681503300022048400259347
    7LZ-203-4.2-11902038251-3119-7/8~12-1/46-5/8REG6-5/8REG7:84.21510-3410399-90156-1269.761416217901607214.64212432685241081503300022048400288386
